The special planks from the Herringbone collection allow you to install the vinyl sheets in a variety of ways
- Enables individual installation In addition to the classic herringbone installation, you can lay the planks in ladder and block installation
- suitable for almost all areas can be used in almost all rooms, whether in shops, restaurants or private living areas
- resilient and easy to maintain long life of the floors with low maintenance requirements
- environmentally conscious floor production
The name PROJECT FLOORS has been associated with high-quality LVT floor coverings since 1999. The abbreviation "LVT" stands for luxury vinyl tiles and indicates that these are PVC-based floorings. The PVC designs from PROJECT FLOORS are available in ceramic concrete, sand or plain colour finishes that replicate the look of natural materials. They combine the authentic look of the original materials with the robustness and ease of care of synthetic floor coverings.
|Length in mm||457|
|Width in mm||76|
|Thickness in mm||2.5|
|suitable for||Business, Industry, Bath, Kitchen, Bedroom & living room, Hallway & Corridor|
|Underfloor heating||Warmwasser-FBH geeignet|
|Warranty||15 Jahre Privat, 5 Jahre Gewerbe|
|Special features||Pet Friendly|
|Piece per package||96|
|Wear layer||0,55 mm|
|Package Content||3.34 m²|
Show all data ▼
|Project Floors Herringbone - Datenblatt|
|Project Floors Herringbone - Verlegeanleitung|
|Project Floors Herringbone - Reinigung und Pflege|
|Project Floors Herringbone - Klebstoffempfehlung|
|Indoor Air Comfort Gold - Zertifikat|
We will help you with your questions!
A specialist adviser will be happy
to advise you personally.
☎ +49 5222 960 4810
Mon - Fri: 9am - 9pm
Sat: 9am - 2pm
Variant: DIY instruction wet bed bonding & Silent Stick
The substrate should be permanently dry, load-bearing and even. Any unevenness should be sanded down and filled with a floor levelling compound. The surface to be laid can then be cleaned with a hoover.
CAUTION: Never install Silent Stick over a soft subfloor, e.g. carpet, cork or any type of foam underlay.
The vinyl planks should be stored horizontally in the room in which it is to be installed for at least 24 hours before installation in the packages. This will allow the material to acclimatise to the room temperature and not "work" so hard after the installation.
Before laying, it is imperative that the official laying instructions, which are included in every package, are followed, otherwise any claim to warranty and guarantee will be invalidated!
Silent Stick (alternative to adhesive):
Now you can lay out the sheets in the opposite direction to the direction in which the top layer is laid. The foil side should always face upwards. Simply cut the Silent Stick to size with a cutter knife.
As soon as the strips have been laid butt to butt, the foil is removed area by area (approx. 2 planks wide) and the vinyl planks can be glued on and pressed down.
ATTENTION: There must always be a gap of approx. 5mm between the flooring and the wall and between the flooring and all fixed components.
Afterwards, the laid surface is rolled with a roller and the skirtings can be fixed. Please note the drying times of the adhesive. If you have a large area, we recommend that you roll the laid planks after approx. 20-30 minutes so that no air bubbles form.
Classic wet-bed gluing:
Before applying the adhesive, open the packages and lay the elements from different packages in alternation to obtain an even decorative pattern in the area. Mark the reference points using a chalk line and cut the vinyl planks to size with a cutter knife. The planks can now be broken by simply folding them.
Apply the adhesive with a notched trowel and lay the vinyl planks in the wet bed, observing the flash-off times of the adhesive. The elements should be placed in the adhesive with little tension and with tight joints and pressed on. When doing so, observe the laying direction on the back of the vinyl planks.
ATTENTION: A gap of approx. 10mm must always be maintained between the flooring and the wall as well as to all fixed components.
The laid surface is then rolled with a roller and the skirting boards can be fixed. Please note the drying time of the adhesive. The glued surface should be rolled after approx. 20-30 minutes so that no air bubbles form.
- Planeo Silent Stick / adhesive
- Cutter knife
- Folding rule
- Toothed spatula for wet bed bonding
- Skirting boards
- Silent Stick: approx. 3-4 hours for 15-20m².
- Wet bed bonding: approx. 6 hours for 15-20m².
- Silent Stick: easy
- Wet bed bonding: difficult
