Rigid vinyl is a new development of classic vinyl flooring and can be used for many applications. The main differences to classic vinyl flooring are the addition of stone dust to the substrate. carrier material. They ensure very robust and rigid properties. This is why the Rigid Board in technical jargon. The Rigid Board improves several properties of the vinyl floor.
- low stretch and shrinkage behaviour
- SPC carrier (Stone-Powder-Composite)
- deformation & dimensionally stable
- allows large-area installation without expansion joint
- can be laid on old floor coverings such as tiles, PVC, linoleum or old old floorboards
Planeo always has special items to offer at an absolute special price. Here you will find flooring from well-known manufacturers and brands in limited remaining quantities. These floors are always sold out quickly. Therefore, our recommendation is: Secure your bargain and save a lot of money. The special items are mostly leftover stocks of discontinued items or sale items to make room for new goods. We buy remaining stock at a lower price, from which you profit directly. It is therefore possible that you can get high-quality brand-name articles at bargain prices here. That's why you don't have to worry: Despite the low prices, these are not second choice items. We make sure that you get impeccable material. We are also happy to provide information about this if you ask us.
planeo is the brand for professional solutions with tested quality. In our extensive range, you will find first-class products for home and garden, from floors to wall coverings to decking: we offer you suitable items with a top price-performance ratio for almost every requirement and budget. We also have product lines such as carpets, wall paints, wallpapers and doors. The range of attractive offers for walls, floors and patios is rounded out by high-quality accessories and effective cleaning and maintenance products. Meanwhile, planeo's services go beyond the trade in floor coverings.
We put great emphasis on the idea of service in everything we do. We deal with the topics of material, handling and realisation in such detail that we can provide you with an adequate solution for many different situations on the building site. To make things more clear, you can find useful tips and instructions in our guides with articles and videos. Beautiful flooring and more? Realise easily with planeo.
|Length in mm||1220|
|Width in mm||180|
|Thickness in mm||3.5|
|Wear layer||0,20 mm|
|suitable for||Bedroom & living room, Hallway & Corridor|
|installation pattern||Plank pattern (1-plank)|
|Underfloor heating||Warmwasser-FBH geeignet|
|Piece per package||12|
|Package Content||2.64 m²|
Show all data ▼
|planeo Rigid Klick-Vinyl - technisches Datenblatt|
|planeo Rigid Klick-Vinyl - Verlegeanleitung|
We will help you with your questions!
A specialist adviser will be happy
to advise you personally.
☎ +49 5222 960 4810
Mon - Fri: 9am - 6pm
Sat: 9am - 2pm
Variant: DIY Instruction
Check the subfloor. Any unevenness that exceeds 3 mm over a length of 1 m should be sanded down or filled with a floor levelling compound. Then clean the surface to be laid with a hoover.
CAUTION: Never install vinyl over a soft subfloor such as carpet, cork or any type of foam underlay.
The vinyl planks should be stored horizontally in the room where it is to be installed for at least 48 hours before installation in the packages. This will allow the material to acclimatise to the room temperature and not "work" so hard after installation.
Before laying the floor, it is imperative to follow the official laying instructions, which are included in every package, otherwise any claim to warranty and guarantee will be void!
Before laying out the floor, check the wall you are starting on and make sure it is at right angles to the opposite wall. If the impact sound insulation is not already integrated, we now recommend spreading out the insulation.
Tips for the UniClic system: To achieve as uniform a floor appearance as possible, it is recommended to install panels from different packages mixed together. You should start laying in a corner (left) and starting from the wall. Lay the first plank with the tongue side facing the wall. Then snap the second plank into the first from the top on the face side. In the second row, the plank is placed at an angle to the end face of the row already laid and folded down. While folding down, the long side of the plank is clicked into the existing plank. With a little pressure, the click joints now snap into place. The transverse joints (front side) should be offset by at least 30 cm from row to row ("wild bond", half a plank length for tile formats). You can use a tapping block and a light tap on the long side of the plank to help it along. To cut a plank, now take measurements and mark the plank. Then take an angle and tear the plank with a multi-purpose knife/cutter and break it off.
Place the spacers on walls, door frames, fixed wall cabinets, kitchen units, etc. so that you have an expansion gap of approx. 5-10mm for underfloor movement or expansion of the product. To install the last row, it is recommended to use the floor layer's jointing iron from the accessories. When using skirting boards, make sure that the expansion joint is covered by the skirting board. If the floor is sealed, e.g. in the bathroom, the PE round cord is now inserted into the expansion joint and the floor sealed with a silicone joint.
Finally, cut off the PU film approx. 2 cm high and attach the skirting boards.
- Click vinyl flooring
- Impact sound insulation
- Cutter knife
- Rubber mallet
- Measuring tape
- Skirting boards
- PE vapour barrier*
- for a room size of 15-20 m² approx. 4-5 hrs.
*required for floors with HDF core board and cork impact sound insulation
