planeo Rigid vinyl flooring oak nature brushed - impact sound integrated

State-of-the-art click vinyl with Rigid SPC core board and already integrated insulation underlay

    • Rigid SPC - mineral high density carrier board.
    • Even easier to work with.
    • Lower swelling and shrinkage behaviour.
    • Suitable for private and commercial use.
    • Phthalate-free - no harmful plasticisers.
    • Well suited for renovations due to low build-up.
› Technical Details
item no. 60205

Request a quote now

planeo

UVP €57.20

Package price (1,30 m²):
€51.35
Price 1 m²:
€39.50
incl. VAT - plus €94.95 shipping costs for CH  M

Include 5% blend

Your delivery date: until Thursday 13. October

  • Storage at the desired date - free of charge for up to 90 days3
  • Customer service until 9pm¹ - personal & close
  • DIY Videos - DIY instructions
1
2
3

We just need your E-Mail and shipping address.

Feel free to add more samples to your sample cart afterwards.

Description

Rigid Vinyl is a new development of classic vinyl flooring and is suitable for many applications. The main differences to classic vinyl flooring are the addition of stone dust to the substrate. in the carrier material. They ensure very robust and rigid properties. This is why the Rigid Board in technical jargon.

  • Dimensionally stable
  • Rigid Board improves several properties of vinyl flooring. Rigid Vinyl is less sensitive to temperature fluctuations. At the same time, the stretching and shrinking behaviour is greatly reduced. The SPC (Stone-Powder-Composite) backing stabilises Rigid Vinyl against deformation.
  • Renovation-friendly
The stable Rigid Board also allows large-area installations in one piece without transition profiles. Lay Rigid Vinyl without much preparation, even on old floor coverings such as tiles, PVC, linoleum or old floorboards.


  • Integrated insulation underlay
  • Rigid SPC - ultra strong
  • easy processing
  • ideal for kitchen & bathroom
  • phthalate-free
  • well suited for renovations

planeo is the brand for professional solutions with tested quality. In our extensive range, you will find first-class products for home and garden, from floors to wall coverings to decking: we offer you suitable items with a top price-performance ratio for almost every requirement and budget. We also have product lines such as carpets, wall paints, wallpapers and doors. The range of attractive offers for walls, floors and patios is rounded out by high-quality accessories and effective cleaning and maintenance products. Meanwhile, planeo's services go beyond the trade in floor coverings.

We put great emphasis on the idea of service in everything we do. We deal with the topics of material, handling and realisation in such detail that we can provide you with an adequate solution for many different situations on the building site. To make things more clear, you can find useful tips and instructions in our guides with articles and videos. Beautiful flooring and more? Realise easily with planeo.



Technical Details
item no. 60205
Manufacturer planeo
Collection planeo Rigid
Length in mm 1219
Width in mm 178
Thickness in mm 5
Wear layer 0,30 mm
Use class 23/31
suitable for Bath, Kitchen, Bedroom & living room, Hallway & Corridor
installation pattern Plank pattern (1-plank)
Installation type click
Wood type Natural oak
Look Wood effect
Sorting (grain) lively/rustic
Underfloor heating Warmwasser-FBH geeignet
Special features Integrated impact sound
EAN 4062212006375
Piece per package 6
Structure Rigid SPC
Shipping group M
Colour brown
Style Vintage
Weight 11,05 kg/Packing
Package Content 1.3 m²
Show all data ▼

Downloads
planeo Rigid Vinylboden - Produktdatenblatt
planeo Rigid Vinylboden - Verlegeanleitung
planeo Rigid Vinylboden - Datenblatt

We will help you with your questions!


A specialist adviser will be happy
to advise you personally.


☎ +49 5222 960 4810
Mon - Fri: 9am - 9pm
Sat: 9am - 2pm

Product questions

Installation instructions for click-vinyl panels with integrated impact sound insulation

Variant: DIY instructions

button
1. Substrate preparation

Check for dust and level out any unevenness at the start. A screed scraper can easily remove minor bumps. You can use a spirit level to check whether the surface is smooth enough on a regular basis. Using a vacuum cleaner, clean the entire surface.

button
2. Acclimatization

For at least 48 hours prior to installation, the vinyl planks should be stored horizontally in the packs in the room where they will be installed. This allows the material to acclimate to room temperature and reduces the amount of "work" required after laying.

button
3. Laying instructions

Before laying of the planks, the official laying instructions included in each package must be followed; otherwise, any warranty and guarantee claims will be invalid!

It is best to mix and lay floorboards from different packs to achieve the most uniform floor possible. Using the 5 mm tapping block and a hammer, join the next complete plank to the front of plank 1. Lay the remaining planks in this row in the same manner across the entire width of the room. When working with a hammer and tapping block is not possible due to a lack of space, you can use a pull bar to click the front connection together. To cut a plank, first measure and mark it. Then, using a square, score the plank with a utility knife, cut through, and snap off the back impact sound insulation. You can easily create and lay the floor sections in the next row.

ATTENTION: When laying, keep the edge distances of 5mm.

button
4. Attach baseboards

Finally, attach the baseboards with a mounting adhesive.

You need this to do it yourself

Material:

  • Click-vinyl with integrated impact sound insulation

Tools:

  • Professional cutter knife
  • Angle
  • Pencil
  • Pull bar
  • Tapping block
  • Rubber mallet
  • Measuring tape
  • Spacers
  • Spirit level

Optionally:

  • Baseboards
  • PE vapour barrier*

Working time:

  • 4-5 hours for a room size of approx.15-20 m².

Difficulty level:

  • Easy

*Required for floors with HDF core board and cork impact sound insulation
