To determine the appropriate order size of the planeo roller blind, please note the following information:
General roller blind dimensions:
Roller blind: The specified width is the length of the tube. For all roller blinds, the overall system is 3 cm wider. Assume that the width shown is 60 cm. This means that the tube length is 60 cm. The length of the total system, tube plus suspension, is then 63 cm. Please take this into account, especially if you want to hang the roller blind in the frame.
Mounting in the window recess:
Hang the roller blind between the walls or in the frame (advantage: better insulation).
- Determining size:
- Width: Measure the width of the frame at the top, in the middle and at the bottom. Order the smallest measurement minus 1 cm.
- Height: Measure the height of the frame on both the left and right sides. Order the highest measured height.
Mounting in front of the window recess:
Hang roller blind in front of the frame, on the wall or on a door (advantage: 1. window appears larger 2. less attractive window frames are concealed).
- Determining size:
- Width: Measure the width, including the desired overlap. You can determine the desired overlap yourself. We recommend measuring 5 cm more per side. Let's say your window frame is 75 cm wide and you want 5 cm overlap on both sides. Then choose a product of 85 cm. Please note that the fabric of the product is sometimes narrower than the overall system.
- Height: Measure the height, including any overlap.
planeo is the brand for professional solutions with tested quality. In our extensive range, you will find first-class products for home and garden, from floors to wall coverings to decking: we offer you suitable items with a top price-performance ratio for almost every requirement and budget. We also have product lines such as carpets, wall paints, wallpapers and doors. The range of attractive offers for walls, floors and patios is rounded out by high-quality accessories and effective cleaning and maintenance products. Meanwhile, planeo's services go beyond the trade in floor coverings.
We put great emphasis on the idea of service in everything we do. We deal with the topics of material, handling and realisation in such detail that we can provide you with an adequate solution for many different situations on the building site. To make things more clear, you can find useful tips and instructions in our guides with articles and videos. Beautiful flooring and more? Realise easily with planeo.
|Roller blind type||Window roller blind|
|Length in mm||1900|
|Width in mm||600|
|Mounting type||without drilling, screwable|
|Ability to be shortened||shortenable|
|Thermal insulation||highly reflective|
|Piece per package||1|
|suitable for||Bath, Bedroom & living room|
|Free shipping DE||Yes|
|Length in cm||190|
|Width in cm||60|
|Package Content||1 Pc|
