planeo DIYtile floor tiles Urban - 60 x 60 x 12.5 cm concrete HT

Name: planeo DIYtile floor tiles Urban - 60 x 60 x 12.5 cm concrete HT
Brand: planeo
SKU: pf432320HDT
Availability: InStock

Innovative ceramic system flooring made of porcelain stoneware for floating installation on existing subfloors

Item no.: pf432320HDT

The DIY floor tile may only be processed with the special joint compound, otherwise the warranty claim will expire.

5kg special joint compound is enough for approx. 26m².

8x faster than conventional tiling.
HT finish: water and mould repellent.
Acoustic and constructive decoupling from the subfloor.
Integrated cork layer on the back.
Crack bridging.
Emission-free installation.
No priming of the substrate necessary.
Removal without residue.
Suitable for electric and hot water underfloor heating.

The DIY floor tile may only be processed with the special joint compound, otherwise the warranty claim will expire.

5kg special joint compound is enough for approx. 26m².

8x faster than conventional tiling.
HT finish: water and mould repellent.
Acoustic and constructive decoupling from the subfloor.
Integrated cork layer on the back.
Crack bridging.
Emission-free installation.
No priming of the substrate necessary.
Removal without residue.
Suitable for electric and hot water underfloor heating.

Offer request

Description

Technical data

Product description

The DIY floor tile may only be processed with the special joint compound, otherwise the warranty claim will expire.

5kg special joint compound is enough for approx. 26m².

8x faster than conventional tiling.
HT finish: water and mould repellent.
Acoustic and constructive decoupling from the subfloor.
Integrated cork layer on the back.
Crack bridging.
Emission-free installation.
No priming of the substrate necessary.
Removal without residue.
Suitable for electric and hot water underfloor heating.

planeo DIYTile tiles revolutionise conventional tiling with their loose-floating installation method. The advantages over conventional tiling are the enormous time savings and the residue-free removal.

The entire strength of the floor is created by the enormous flank adhesion of the joint to the system panel.

Special features:

The cork layer on the back ensures that the tile adheres firmly to the floor by its own weight.
no gluing, no mortar bed - the floor covering can be walked on immediately after installation.
can be replaced with little effort and is environmentally friendly to dispose of, as the material is made from natural raw materials
excellently suitable for electric or hot water underfloor heating
HyTect finish Water rolls off
when light hits the tile, fungi and bacteria are decomposed and unpleasant odours are removed

Important to note: The grouting of the system floor may only be carried out with the corresponding planeo special grout!

planeo

planeo is the brand for professional solutions with tested quality. In our extensive range, you will find first-class products for home and garden, from floors to wall coverings to decking: we offer you suitable items with a top price-performance ratio for almost every requirement and budget. We also have product lines such as carpets, wall paints, wallpapers and doors. The range of attractive offers for walls, floors and patios is rounded out by high-quality accessories and effective cleaning and maintenance products. Meanwhile, planeo's services go beyond the trade in floor coverings. We put great emphasis on the idea of service in everything we do. We deal with the topics of material, handling and realisation in such detail that we can provide you with an adequate solution for many different situations on the building site. To make things more clear, you can find useful tips and instructions in our guides with articles and videos. Beautiful flooring and more? Realise easily with planeo.

item no.: pf432320HDT

easy to assemble
UV-resistant
loose laying
emission-free
shock-resistant
fully recyclable

Technical data

item no.	pf432320HDT
Colour	grey
Piece per package	1
Special features	Umweltfreundlich, Rutschfest, Anti-Schimmel, DIY-Fliesen
suitable for	Bad, Küche, Schlaf & Wohnzimmer, Diele & Flur
installation pattern	Tile format
Installation type	loose-laying
Underfloor heating	suitable
Structure	Ceramics + Cork
Look	Steinoptik
Length in mm	597
Width in mm	597
Shipping group	L
Manufacturer	planeo
Material	Ceramics
Thickness in mm	12.5
Type	Floor tile

Downloads

Print page

DIY step by step

Variant: DIY-Instruction

button

1. substrate preparation

The substrate should be permanently dry, load-bearing and even. Any unevenness should be sanded down and filled with a floor levelling compound.

ATTENTION: Observe the tolerance value of max. 2 mm per linear metre, so that the butt edges of the tiles remain nice and even. The surface to be laid can now be cleaned with a hoover.

The tiles should be stored in the room where they are to be laid for at least 24 hours before installation. This will allow the material to acclimatise to the room temperature and it will not "work" so hard after the installation.

button

2. installation planning

Measure the room exactly and plan the installation. To do this, you can determine the centre of the room with the help of a chalk line. Then mark the starting line.

Before laying the flooring, it is imperative that you follow the official laying instructions that are included in every package, otherwise any claim under warranty and guarantee will be invalidated!

button

3. laying instructions

Now you can start laying the tiles. To do this, place the first tile well aligned with the markings. With the help of a suction cup, the other tiles are laid along the markings. As soon as the first strip is in place, the next tiles can be laid butt to butt with the tiles already in place.

ATTENTION: A distance of at least 8 mm must always be maintained between the flooring and the wall as well as to all fixed components.

button

4. grouting

Mix the joint provided for this purpose, taking into account the mixing ratios. The joint can then be filled into the spaces between the tiles using a spatula or trowel. Fill up to two rows at a time and wipe off the joint with a sponge board. When doing this, wipe against the joint so that the compound can spread well in the gaps.

button

5. finish

Finally, the skirting boards can be fitted.
